CNC LASER CUTTING

Sheet Metal Kent Laser Cutting

Sheet Metal Kent Laser Cutting

Sheet Metal Kent Laser Cutting

state of the art laser cutting technology
giving excellent capacity and capability

Our TRUMPF and LVD laser cutting machines running daily give us excellent capacity for long running batch jobs, in addition to flexibility for getting smaller jobs completed quickly. Brand new for 2023, our 12kw Puma 3015 Fiber Laser offers the latest state of the art laser cutting technology, enabling us to cut bigger and thicker material than ever before.

Our new LVD machine will really propel us forward in the laser cutting market. The whopping 12kw of power will give us massively increased cutting speeds and a higher quality cut on materials up to 30mm in thickness.

Our machines connect directly with our CAD System for quick interaction and for fast manufacture if design changes need to be made.

We have a combination of a manual crane in addition to an automated robotic crane for loading sheets, again giving us a variety of options for the vast array of components that we laser cut.

Get in touch today for us to provide a laser cutting quote.


cutting capabilities

Working Range

  • X axis - 3000 mm

  • Y axis - 1500 mm

  • Z axis - 75 mm

Materials & Thicknesses

  • Mild steel - 20 mm

  • Stainless Steel - 16 mm

  • Aluminium - 12 mm

  • Copper - 6 mm

  • Brass - 6 mm


how it works

Laser Cutting and Laser Profiling machines can handle a variety of cutting tasks. These range from micrometer-precise cutting joints in paper-thin semiconductor chips to quality cuts in 30-millimeter-thick steel. In laser drilling, the laser beam generates very small to large holes in metals, plastics, paper and stone, without contact.



Where the focused laser beam strikes the workpiece, it heats the material so extremely that it melts or even vaporizes. Once it has completely penetrated the workpiece, the cutting process can start: the laser beam moves along the part contour, melting the material as it goes. Usually, a stream of gas blows the melted material downwards, out of the cut. The gap is barely wider than the focused laser beam itself.



In laser drilling, a short laser pulse melts and vaporizes the material with a high power density. The resulting high pressure drives the molten material out of the hole.


cutting gases

Our two Laser Cutting machines will use one of three types of cutting gases, depending on the material and thickness of the sheet metal component.

Compressed Air, Oxygen or Nitrogen. We recently had a new 10,000L Nitrogen Tank installed at our premises here in Kent, meaning we have much less down time and better efficiency on the laser cutters.

INTRODUCING OUR BRAND NEW...

LVD 12kw Puma 3015 Fiber LaseR

Complete with automatic loading crane and nozzle changer

With our existing laser cutter at 3kw, this new machine will really propel us forward in the laser cutting market. The whopping 12kw of power will give us massively increased cutting speeds and a higher quality cut on materials up to 30mm in thickness.



This machine replaced our old CO2 laser which we had since 2005, and will also be a far more energy efficient option.



Combined with our existing Trumpf 2030 Fiber, our two 3000x1500 flatbed laser cutters takes our laser cutting capacity to a whole new level.

Puma1
Puma3
Puma4
064347_645a67f883004123a9318e974f065a3d~mv2

Fiber-Optic TruLaser 2030
The Latest State of the Art Technology in Sheet Metal Laser Cutting & Laser Profiling



The TRUMPF TruLaser 2000 Series offers the latest state-of-the-art technology to meet the highest standards in quality, reliability and efficiency in Laser Cutting and Laser Profiling. It combines the advantages of a compact machine with the performance of higher machine classes.



Our machine, which was installed in August 2016, allows us to cut more types of materials at a greater thickness, enabling us to offer our customers a much wider variety of product specifications. Together with higher laser cutting performance and optional automation, our capacity, flexibility and production times for our clients across Kent, the South East and all of the UK have significantly improved.

Sheet Metal Kent Laser Cutting
Sheet Metal Kent Laser Cutting
Sheet Metal Kent Laser Cutting
Sheet Metal Kent Laser Cutting
Sheet Metal Kent Laser Cutting
Sheet Metal Kent Laser Cutting
Sheet Metal Kent Laser Cutting

Choose Allbart for your Cnc laser cutting

  • Over 45 years experience in Sheet Metal Subcontract Manufacture.

  • Our loyal and repeat customer base is testament to the excellent level of quality and service that we have offered for decades.

  • Allbart has a vastly experienced and capable team to manufacture your parts from start to finish. We have an extremely low staff turnover with more than two thirds of our staff having been in the company for over 10 years. Testament to a family owned and run company.

  • ISO 9001:2015 accreditation ensures excellent quality inspection and rigorous systems in place from start to finish to ensure we maintain our high quality standards.

  • We offer the full array of services. Unlike a lot of sheet metal subcontractors, we offer a one-stop service where we operate all services in house from the design and technical aspects, to cutting, forming, finishing and even delivery. This enables us to better control quality and give our customers a better price.

  • A growing company re-investing in the latest state of the art sheet metal fabrication technology. In recent years we have extended our premise to a 25,000 square feet facility and invested heavily in new machinery such as Fibre Laser Machines and Press Brakes.

  • We have room for further capacity - so we would love to hear from you today and talk you through how we can help. Get in touch to speak to one of the team
